Description
Electronic condensate drain valve which ensures a safe discharge of condensate while preventing wasteage of compressed air.
Includes a manual override, power on display, alarm light and potential free contact for remote monitoring.
Max operating pressure: 16 bar
Operating voltage:
Bekomat 31U, 32U & 33U: 95 - 230V AC
Bekomat 13 & 14: 230V AC
Housing Protection:
Bekomat 31U, 32U & 33U: IP 67
Bekomat 13 & 14: IP 65
A service kit including overhaul kit for valve and all O Rings can be ordered separately.
The service unit for Bekomat 31U, 32U and 33U is a one piece unit for quick swap over.
The Bekomat drain valve should be sized according to the capacity of the system and where it is fitted from the table shown.
Available on request:
Valves suitable for other operating voltages and higher pressure
Corrosion-proof design to handle condensate from oil-free compressors
Valve fitted with thermostatically controlled heater
Valve with larger capacity
Ex version for explosive atmospheres
Technical Details
|
Datasheets
Bekomat_31U_32U_33U_33UCO
Bekomat_12_13_14_16
bekomat_31u_manual_en_01-1607_v01
|
